High Performance, Simple Inverter FC90 Series

FC90P Series mini VFD

SKU:
Availability:

Quantity:



FC90P: Big Performance in a Small Package. The FC90P Series Designed specifically for space-constrained and cost-sensitive applications, it packs a complete set of industrial control features into an incredibly compact footprint. Smart & Compact: Small size doesn't mean simple. FC90P includes Built-in PID for constant pressure control and Simple PLC for automated sequences. Ready for light-duty Machinery: With a 0-3200Hz range and open loop vector controls, it is perfect for pumps, fans, food processing, and solar water pump. Stable & Reliable: Supports a wide voltage fluctuation range (-15% to +20%), making it the most stable choice for regions with unstable power grids. Customization supported: Ultra-simple commissioning and branding-friendly design make it the ideal entry-level platform to grow your brand fast.
Inquire Add to Basket

Model:
FC90P
Brand:
Janson Controls

Item No.	Adaptable Motor (kW)	Input Current (A)	Output Current (A)	Rate Capacity (kVA)	W (mm)	H (mm)	D (mm)	W1 (mm)	H1 (mm)	d (mm)
1 Phase Input and 3 Phase Output 220V (-15%~+15% Tolerance)
FC90P-2S-0.4G	0.4	6.5	2.1	0.7	68	164	111	53	151	Ø4
FC90P-2S-0.75G	0.75	8.2	4.0	1.5
FC90P-2S-1.5G	1.5	14	7.0	3.0
FC90P-2S-2.2G	2.2	23	9.6	4.0	89	217	146	64	206	Ø5.3
3 Phase Input and 3 Phase Output 220V (-15%~+15% Tolerance)
FC90P-2T-4.0G	4.0	14.6	13	8.9	89	217	146	64	206	Ø5.3
3 Phase Input and 3 Phase Output 380V (-15%~+15% Tolerance)
FC90P-4T-0.75G	0.75	3.4	2.1	1.5	68	164	111	53	151	Ø4
FC90P-4T-1.5G	1.5	5.0	3.8	3.0
FC90P-4T-2.2G	2.2	5.8	5.1	4.0
FC90P-4T-4.0G	4.0	10.5	9.0	5.9	89	217	146	64	206	Ø5.3
FC90P-4T-5.5G	5.5	14.6	13	8.9
FC90P-4T-7.5G	7.5	19	17	11

Electrical Specification
Input Voltage	Single Phase/Three Phase 200~240V, Three Phase 380~440V Fluctuate no more than±10%，Imbalance Rate <3%
Input Frequency	50/60Hz ± 5%
Output Voltage	0V~Input Voltage
Output Frequency	V/F Control：0~3200Hz Open-loop vector control:0~500Hz
Performance
Overload Capacity	150% rated output current for 1 minute, 180% rated output current for 2 seconds
Control Method	V/F control, Open-loop vector control
Run Command Setting Method	Operation Panel Setting, External Terminal Setting,Communication Setting.
Speed Setting Method	Digital setting, analog setting, communication setting.
Speed Setting Resolution	Digital setting: 0.01Hz, Analog setting: 1% × maximum frequency.
Special Feature
Programmable Input & Output Terminals	Input& Output terminal function can be edited
Process PID Adjustment Function	Built-in process PID module
Simple PLC Function	Built-in simple PLC module, which can realize timing and multi-segment frequency output.
Motor group parameters	Two sets of motor parameters (motor parameter 1 and motor parameter 2), switch between them at will.
Protective Function
Automatic Current Limiting Protection	Output current is automatically limited to prevent over-current faults
Overload Pre-Alarm & Alarm	Overload Pre-warning and protection
Output Phase Loss Protection	Output phase loss automatic detection and alarm function
Overvoltage & Overflow Stall Control	Automatically limit current and voltage during operation to prevent frequent over-current and over-voltage tripping
Output Short-to-Ground Protection	Effective protection function for output short circuit to ground
Output Phase-to-Phase Short Circuit Protection	Output interphase short circuit effective protection function
Input & Output
External analog power supply	+10V，load capacity 100mA
Analog Input	AI： 0~10V/0-20mA(Voltage/current selectable)
Analog Output	AO：0~10V / 0~20mA(Voltage/current selectable)
Digital Input	DI1~DI5
Digital Output	DO
Relay output	TA/TB/TC：Contact rating 250VAC/3A or 30VDC/1A
MODBUS Communication	A+、B-
Operation Display
LED Display	5-digit LED digital Set frequency, output frequency, output voltage, output current, motor speed, output torque, digital terminals, status parameters, programming menu parameters and fault codes etc.
Indicator Light	3 units indicators, 3 status indicators
Environmental Characteristics
Working Temperature	-10~+40℃, Maximum temperature is 50°C, Air Temperature change is less than 0.5°C/min,40~50℃ Derating is required, output current derating 2% for each 1℃
Storage Environment Temperature	-40~+70℃
Application	Indoor, free from direct sunlight, dust, corrosive gas, flammable gas, oil mist, water vapor, dripping water or salt etc.
Altitude	Less than 1000 meters, derating is required for more than 1000 meters.
Humidity	Less than 95%RH, no condensation
Vibration resistance	3.5m/s² at 2~9Hz, 10m/s² at 9~200Hz (IEC60721-3-3)
Protection Degree	IP20
Pollution Level	Class 2 (dry, non-conductive dust pollution)
