The DM100 Series is an integrated, variable-frequency drive and control system specifically engineered for door operation. It seamlessly combines door opening/closing logic control with motor driving circuitry in a single unit, receiving commands from external systems to manage the entire door motion profile.
Capable of driving both AC induction and permanent magnet synchronous motors, and supporting both speed-based and encoder-feedback distance control, the DM100 offers exceptional versatility. This makes it a compact, intelligent, and highly adaptable core solution capable of meeting the drive and control demands of a wide array of automatic door systems.
Drive & Control in One Unit: Integrates door operation logic control and motor drive circuitry into a single controller, significantly simplifying system architecture and saving installation space and cost.
Dual-Mode Precision Control: Supports both encoder-based distance control (for precise positioning) and speed control via deceleration switches, meeting the high demands of different door types for motion profiles.
2. Wide Compatibility, Flexible Adaptation
Excellent Motor Compatibility: Capable of driving both AC induction motors and Permanent Magnet Synchronous Motors (PMSM), providing extensive freedom in motor selection for door system design.
Convenient Extended Operation: The operation panel can be externally connected, facilitating parameter viewing and debugging when the installation location is inconvenient, enhancing user experience.
3. Intelligent & User-Friendly, Rapid Deployment
One-Key Parameter Setting: Features built-in intelligent commissioning, enabling one-key self-tuning to eliminate complex on-site debugging and significantly reduce installation time.
Plug-in Terminal Blocks: Utilizes a plug-in terminal block design, making electrical wiring simpler, more reliable, and easier to maintain.
1. Highly Integrated, Simplifying Complexity
Drive & Control in One Unit: Integrates door operation logic control and motor drive circuitry into a single controller, significantly simplifying system architecture and saving installation space and cost.
Dual-Mode Precision Control: Supports both encoder-based distance control (for precise positioning) and speed control via deceleration switches, meeting the high demands of different door types for motion profiles.
2. Wide Compatibility, Flexible Adaptation
Excellent Motor Compatibility: Capable of driving both AC induction motors and Permanent Magnet Synchronous Motors (PMSM), providing extensive freedom in motor selection for door system design.
Convenient Extended Operation: The operation panel can be externally connected, facilitating parameter viewing and debugging when the installation location is inconvenient, enhancing user experience.
3. Intelligent & User-Friendly, Rapid Deployment
One-Key Parameter Setting: Features built-in intelligent commissioning, enabling one-key self-tuning to eliminate complex on-site debugging and significantly reduce installation time.
Plug-in Terminal Blocks: Utilizes a plug-in terminal block design, making electrical wiring simpler, more reliable, and easier to maintain.
Item No.
Adaptable Motor (kW)
Input Current (A)
Output Current (A)
Rate Capacity (kVA)
W (mm)
H (mm)
D (mm)
GW (kg)
1 Phase Input and 1 Phase Output 220V (-15%~+20% Tolerance)
DM100-2S-0.2
0.2
2.7
1.3
0.5
213.7
147
66
1.00
DM100-2S-0.4
0.4
5.4
2.3
1.0
DM100-2S-0.7
0.7
8.2
4.0
1.5
Item No.
Adaptable Motor (kW)
Input Current (A)
Output Current (A)
Rate Capacity (kVA)
W (mm)
H (mm)
D (mm)
GW (kg)
1 Phase Input and 1 Phase Output 220V (-15%~+20% Tolerance)
DM100-2S-0.2
0.2
2.7
1.3
0.5
213.7
147
66
1.00
DM100-2S-0.4
0.4
5.4
2.3
1.0
DM100-2S-0.7
0.7
8.2
4.0
1.5
Item
Basic parameters
Basic specifications
Maximum output frequency
99.00 Hz
Speed range
1:50 (SVC) 1:1000 (CLVC) SVC: Sensorless vector control CLVC: Closed-loop vector control
Speed stability
±0.5% (SVC) ±0.05% (CLVC)
Startup torque
1 Hz/150% (SVC) 0 Hz/180% (CLVC)
Frequency resolution
0.01 Hz
Current resolution
0.01 A
Carrier frequency
2–16 kHz
Major functions
Two auto-tuning modes are supported, with-load auto-tuning and no-load autotuning.
For CLVC on the AC PMSM using a common ABZ encoder, opencollector output or push-pull output is supported.
For SVC, functions such as fixed torque boost, customized torque boost and overexcitation are supported.
Door width auto-tuning is supported.
Automatic demonstration is supported.
Automatic identification upon hindering is supported.
Protection functions
Controller overload protection (1 minute for 150% of rated current , 1 second for 180% of rated current) is supported.
Protections on overvoltage, undervoltage, overcurrent, output phase loss and interphase short circuit are supported.
Environment
Installation location
Indoors,Free from direct sunlight, dust, corrosive gas, combustible gas, oil mist, vapor, drip and salt.
Altitude
Lower than 1000 m Deratedif the altitude is above 1000 m
Ambient temperature
-10°C to +40°C Derated if ambient temperature is within 45–50°C
Humidity
Less than 95% RH, non-condensing
Vibration
< 5.9 m/s2(0.6 g)
Storage temperature
-20°C to +60°C
Cooling method
Natural cooling for 0.2 kW Forced air cooling for 0.4 kW and 0.75 kW
Ingress protection
IP20
Storage location
Indoors, clean and dry
Transportation
Packed in standard box and transported by coach, train, aircraft or ship.
Vibration during transportation
15 m/s2 (1.5 g) when SIN vibration is 9–200 Hz
Item
Basic parameters
Basic specifications
Maximum output frequency
99.00 Hz
Speed range
1:50 (SVC) 1:1000 (CLVC) SVC: Sensorless vector control CLVC: Closed-loop vector control
Speed stability
±0.5% (SVC) ±0.05% (CLVC)
Startup torque
1 Hz/150% (SVC) 0 Hz/180% (CLVC)
Frequency resolution
0.01 Hz
Current resolution
0.01 A
Carrier frequency
2–16 kHz
Major functions
Two auto-tuning modes are supported, with-load auto-tuning and no-load autotuning.
For CLVC on the AC PMSM using a common ABZ encoder, opencollector output or push-pull output is supported.
For SVC, functions such as fixed torque boost, customized torque boost and overexcitation are supported.
Door width auto-tuning is supported.
Automatic demonstration is supported.
Automatic identification upon hindering is supported.
Protection functions
Controller overload protection (1 minute for 150% of rated current , 1 second for 180% of rated current) is supported.
Protections on overvoltage, undervoltage, overcurrent, output phase loss and interphase short circuit are supported.
Environment
Installation location
Indoors,Free from direct sunlight, dust, corrosive gas, combustible gas, oil mist, vapor, drip and salt.
Altitude
Lower than 1000 m Deratedif the altitude is above 1000 m
Ambient temperature
-10°C to +40°C Derated if ambient temperature is within 45–50°C
Humidity
Less than 95% RH, non-condensing
Vibration
< 5.9 m/s2(0.6 g)
Storage temperature
-20°C to +60°C
Cooling method
Natural cooling for 0.2 kW Forced air cooling for 0.4 kW and 0.75 kW
Ingress protection
IP20
Storage location
Indoors, clean and dry
Transportation
Packed in standard box and transported by coach, train, aircraft or ship.
