| Power input |
| Input Voltage | 1AC 220V±15%, 3AC 220V±15%,3AC 380V±15%, 3AC 660V±10%, 3AC 1140V±15% |
| Input Frequency | 47～63Hz |
| Power factor | ≥95% |
| Control performance |
| Control mode | V/F control, non-PG vector control(SVC)，PG vector control (FVC) |
| V/F control | Line, multiple point , square V/F curve, V/F separation |
| Operation command mode | Keypad control, Terminal control, Serial communic-ation control |
| Frequency Reference Source | Digital,analog,pulse frequency,serial communication, multistep speed,simple PLC and PID The combinaton of multimodes and the different modes can be switched. |
| Overloadcapacity | G type:150% rated current 60s,180% rated current 3s |
| P type:120% rated current 60s,150% rated current 3s |
| Start torque | G type:0.5Hz/150%(SVC),0Hz/180%(FVC) |
| P type:0.5Hz/100% |
| Speed adjusting range | 1:100(SVC) 1:1000(FVC) |
| Speedcontrol accuracy | ±0.5%(SVC)±0.02%(FVC) |
| Carrier frequency | 0.5 to 16.0 kHz;automatically adjust carrier frequency according to the load characteristics |
| Frequency resolution | Digital setting:0.01Hz.Anolog setting:maximum frequency x 0.00025 |
| Torque boost | Automatic torque boost;manual torque boost 0.1~30% |
| Acceleration and deceleration mode | Line or S-curve, 4 types of acceleration/deceleration time with the range of 0.0~6500.0 s |
| DC brake | Supports starting and stopping DC brake; |
| JoggingControl | Jog frequency range:0.0Hz~50.00Hz;Jog Acc/Dec time:0~6500.0s |
| Simple PLC & multi step speed operation | Built-in PLC o rcontrol terminal,1 6steps speed can be set |
| Built-in PID | Built-in PID control to easily realize the close loop control for the process parameters (such as pressure, temperature,flow, etc. |
| Automatic voltage regulation(AVR) | Automatically maintain a constant output voltage when the voltage of electricity grid changes |
| Common DC bus | Common DC bus function:multipl einverters can use a common DC bus |
| Traverse control | Traverse control function:multiple triangular pulse frequency control |
| Fixed length control | Setting length control |
| Timingcontrol | Setting time range：0~6500min |
| Main control |
| Input terminals | 6 programmable digital inputs,it can be extended to 4 digital inputs,one of which supports high speed pulse input; 1 analog volatge input 0~10VDC; 2 volatge input 0~10VDC or current input 0~20mA. |
| Output terminals | 1 open collector output ,it can be extened to 1 high speed pulse output ; 2 relay outputs ; 2 analog output: volatge output 0~10VDC or current output 0~20mA. |
| Human Machine Interface |
| LED Display | Can display setting frequency, output frequency, output voltage, output current, etc. |
| Enviorment & Protectionclass |
| Protection class | IP20 |
| Humidity & temperature | 90%RH or less (no-condensation),- 10℃～ +40℃.Inverter will be derated if ambien temperature exceeds 40℃ |
| Vibration | Under 20 Hz 9.8m/s(1G),Over 20Hz 5.88m/s(0.6G) |
| Store environment | ≤1000M,indoor(no corrosive gas and liquid) |
| Store temperature | -20℃～60℃ |
| Cooling Mode | Forced air-cooling |
